5452487
ActivePhoenix Contact
TERM BLOCK HDR 16POS VERT 5MM
5452487
ActivePhoenix Contact
TERM BLOCK HDR 16POS VERT 5MM
Description
General part information
5452487
16 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.197" (5.00mm) Vertical Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 5452487 |
|---|---|
| Color | Black |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.154 in |
| Current - IEC | 12 A |
| Current - UL | 15 A |
| Features | Mating Flange |
| Header Orientation | Vertical |
| Insulation Height | 0.472 in |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 16 |
| Pitch | 0.197 in |
| Positions Per Level | 16 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 320 V |
| Voltage - UL | 300 V |
