2948270
ObsoletePhoenix Contact
LINE FILTER 500VAC CHASSIS
2948270
ObsoletePhoenix Contact
LINE FILTER 500VAC CHASSIS
Description
General part information
2948270
Three Phase (Delta) EMC/EMI Line Filter 500V 50/60Hz Single Stage Terminal Block
Technical Specifications
Parameters and characteristics for this part
| Specification | 2948270 |
|---|---|
| Applications | General Purpose |
| Configuration | Single Stage |
| Filter Subtype | Delta |
| Filter Type | Three Phase |
| Frequency - Operating | 60Hz, 50Hz |
| Frequency - Operating (Max) | 60 Hz |
| Frequency - Operating (Min) | 50 Hz |
| Inductance | 220 nH |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -20 °C |
| Termination Style | Terminal Block |
| Voltage - Rated AC | 500 V |
