MCX Jack, Straight, PCB Receptacle, Surface Mount, Brass Body, 0.02µm Gold (Au) Plated, Tape and Reel, 50 Ohms
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
3D models and CAD resources for this part
Technical documentation and resources
No documents available
MCX Jack, Straight, PCB Receptacle, Surface Mount, Brass Body, 0.02µm Gold (Au) Plated, Tape and Reel, 50 Ohms
| Part | Connector Style | Shield Termination | Fastening Type | Mounting Type | Contact Termination | Frequency - Max | Number of Ports | Impedance | Housing Color | Center Contact Material | Connector Type | Voltage Rating | Operating Temperature (Max) | Operating Temperature (Min) | Body Finish | Center Contact Plating | Dielectric Material | Body Material | Mating Cycles | Cable Group Size | Cable Group | Convert From (Adapter End) | Adapter Series | Conversion Type | Convert To (Adapter End) | Style | Center Gender | Adapter Type | Cable Group Diameter (Semi Rigid) | Features | Insertion Loss |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | MCX | Solder | Snap-On | Surface Mount | Solder | 6000 MHz | 1 | 50 Ohm | Gold | Beryllium Copper | Female Socket Recepture | 335 V | 155 °C | -55 °C | Gold | Gold | Polytetrafluoroethylene (PTFE) | Brass | 500 cycles | ||||||||||||
 Molex | SSMCX | Solder | Snap-On | Board Edge Cutout Surface Mount | Solder | 6000 MHz | 1 | 50 Ohm | Gold | Beryllium Copper | Female Socket Jack | 170 V | 155 °C | -55 °C | Gold | Gold | Polytetrafluoroethylene (PTFE) | 1.37 mm | Coaxial Cable | ||||||||||||
 Molex | Snap-On | Free Hanging (In-Line) | 40 Gbps | 50 Ohm | Beryllium Copper | Gold | Gold | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Female Socket SMP Jack | SMP to SMP | Same Series | Female Socket SMP Jack | Straight | Female | Jack to Jack | |||||||||||||||
 Molex | MMCX | Solder | Snap-On | Through Hole | Solder | 6000 MHz | 1 | 50 Ohm | Gold | Brass | Male Pin Plug | 170 V | 165 °C | -55 °C | Gold | Gold | Polytetrafluoroethylene (PTFE) | Brass | 500 cycles | ||||||||||||
 Molex | MCX | Solder | Snap-On | Through Hole | Solder | 6000 MHz | 1 | 50 Ohm | Gold | Beryllium Copper | Female Socket Jack | 335 V | Gold | Gold | Polytetrafluoroethylene (PTFE) | Brass | 500 cycles | ||||||||||||||
Molex | MMCX | Solder | Snap-On | Free Hanging (In-Line) Right Angle | Solder | 6000 MHz | 1 | 50 Ohm | Gold | Brass | Male Pin Plug | 170 V | Gold | Gold | Polytetrafluoroethylene (PTFE) | Brass | RG-405 | 0.085 in | |||||||||||||
 Molex | SMP | Solder | Snap-On | Surface Mount | Solder | 40 Gbps | 1 | 50 Ohm | Gold | Brass | Male Pin Plug | 335 V | 165 °C | -65 °C | Gold | Gold | Liquid Crystal Polymer (LCP) | Brass | 500 cycles | Limited Detent | 0.1 dB | ||||||||||
 Molex | MCX | Solder | Snap-On | Surface Mount | Solder | 6000 MHz | 1 | 75 Ohm | Gold | Beryllium Copper | Female Socket Recepture | 335 V | 155 °C | -55 °C | Gold | Gold | Polytetrafluoroethylene (PTFE) | Brass | 500 cycles | ||||||||||||
Molex | MCX | Crimp | Snap-On | Free Hanging (In-Line) Right Angle | Solder | 1 | Brass | Male Pin Plug | Gold | Gold | Polytetrafluoroethylene (PTFE) | Brass | RG-179 | ||||||||||||||||||
