AISC-1210-R56J-T
ObsoleteAbracon LLC
INDUCTOR RF WIREWOUND 0.56UH 5% 35MHZ 45Q-FACTOR CERAMIC 0.46A 1.1OHM DCR 1210 T/R
AISC-1210-R56J-T
ObsoleteAbracon LLC
INDUCTOR RF WIREWOUND 0.56UH 5% 35MHZ 45Q-FACTOR CERAMIC 0.46A 1.1OHM DCR 1210 T/R
Description
General part information
AISC-1210-R56J-T
560 nH Unshielded Drum Core, Wirewound Inductor 460 mA 1.1Ohm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | AISC-1210-R56J-T |
|---|---|
| Current Rating | 460 mA |
| DC Resistance (DCR) (Max) | 1.1 Ohm |
| Frequency - Self Resonant | 420 MHz |
| Height - Seated (Max) | 0.106 in |
| Inductance | 560 nH |
| Inductance Frequency - Test | 35 MHz |
| Material - Core | Ceramic |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Q | 45 |
| Shielding | Unshielded |
| Size / Dimension Length | 0.144 in |
| Size / Dimension Width | 0.116 in |
| Tolerance | 5 % |
| Type | Drum Core, Wirewound |
