TEF6904AH/V5S,518
ObsoleteNXP USA Inc.
RF RECEIVER AM/FM 80QFP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TEF6904AH/V5S,518
ObsoleteNXP USA Inc.
RF RECEIVER AM/FM 80QFP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | TEF6904AH/V5S,518 | TEF690 Series |
|---|---|---|
| Antenna Connector | PCB, Surface Mount | PCB, Surface Mount |
| Applications | AM/FM Radio Receiver | AM/FM Radio Receiver, Audio |
| Current - Receiving | 102 mA | 102 mA |
| Data Interface | Surface Mount, PCB | Surface Mount, PCB |
| Grade | - | Automotive |
| Modulation or Protocol | FM, AM | FM, AM, WB, RBDS, RDS |
| Mounting Type | Surface Mount | Surface Mount |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Package / Case | 80-BQFP | 64-BQFP, 80-BQFP |
| Supplier Device Package | 80-QFP (14x14) | 64-QFP (14x14), 80-QFP (14x14) |
| Voltage - Supply [Max] | 9 V | 9 V |
| Voltage - Supply [Min] | 8 V | 8 V |
TEF690 Series
RF RECEIVER AM/FM/WB 64QFP
| Part | Supplier Device Package | Applications | Data Interface | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply [Min] | Voltage - Supply [Max] | Antenna Connector | Modulation or Protocol | Package / Case | Mounting Type | Current - Receiving | Grade |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
NXP USA Inc. TEF6902AH/V2,557 | 64-QFP (14x14) | AM/FM Radio Receiver | PCB, Surface Mount | 85 °C | -40 °C | 8 V | 9 V | PCB, Surface Mount | AM, FM, WB | 64-BQFP | Surface Mount | 102 mA | |
NXP USA Inc. TEF6906H/V2S,518 | 64-QFP (14x14) | Audio | PCB, Surface Mount | PCB, Surface Mount | RBDS, RDS | 64-BQFP | Surface Mount | Automotive | |||||
NXP USA Inc. TEF6904AH/V5S,518 | 80-QFP (14x14) | AM/FM Radio Receiver | PCB, Surface Mount | 85 °C | -40 °C | 8 V | 9 V | PCB, Surface Mount | AM, FM | 80-BQFP | Surface Mount | 102 mA |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
TEF690 Series
- RF Receiver AM, FM PCB, Surface Mount 80-QFP (14x14)
