EHHD15MF

Active

Switchcraft Inc.

CONN DSUB ADAPTER HD15F HD15M

Search across all available documentation for this part.

Active

Switchcraft Inc.

CONN DSUB ADAPTER HD15F HD15M

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	EHHD15MF	EHHD15 Series

Connector Style	Connector Saver	Gender Changer, Connector Saver
Contact Finish	Gold	Gold
Convert From (Adapter End)	15 HD, Male, D-Sub	Female, D-Sub, 15 HD, Male
Convert To (Adapter End)	Female, 15 HD, D-Sub	Female, 15 HD, D-Sub, Male
Housing Color	Yellow	Yellow
Includes	2 Screws, 1 Connector, 1 Flange, 1 Housing	2 Screws, 1 Connector, 1 Flange, 1 Housing
Mounting Type	Panel Mount, Square Flange	Panel Mount, Square Flange
Number of Rows	3	3
Shell Material, Finish	Nickel Silver, Tin Plated	Nickel Silver, Black Chrome Plated, Tin Plated

DSUB GENDER CHANGER HD15F HD15F

Part	Convert To (Adapter End)	Connector Style	Contact Finish	Mounting Type	Housing Color	Convert From (Adapter End)	Shell Material, Finish	Includes	Number of Rows
Switchcraft Inc. EHHD15FFB	15 HD, D-Sub, Female	Gender Changer	Gold	Panel Mount, Square Flange	Yellow	15 HD, D-Sub, Female	Black Chrome Plated, Nickel Silver	1 Connector, 1 Flange, 1 Housing, 2 Screws	3
Switchcraft Inc. EHHD15MFB	15 HD, D-Sub, Female	Connector Saver	Gold	Panel Mount, Square Flange	Yellow	15 HD, D-Sub, Male	Black Chrome Plated, Nickel Silver	1 Connector, 1 Flange, 1 Housing, 2 Screws	3
Switchcraft Inc. EHHD15MM	15 HD, D-Sub, Male	Gender Changer	Gold	Panel Mount, Square Flange	Yellow	15 HD, D-Sub, Male	Nickel Silver, Tin Plated	1 Connector, 1 Flange, 1 Housing, 2 Screws	3
Switchcraft Inc. EHHD15MMB	15 HD, D-Sub, Male	Gender Changer	Gold	Panel Mount, Square Flange	Yellow	15 HD, D-Sub, Male	Black Chrome Plated, Nickel Silver	1 Connector, 1 Flange, 1 Housing, 2 Screws	3
Switchcraft Inc. EHHD15MF	15 HD, D-Sub, Female	Connector Saver	Gold	Panel Mount, Square Flange	Yellow	15 HD, D-Sub, Male	Nickel Silver, Tin Plated	1 Connector, 1 Flange, 1 Housing, 2 Screws	3
Switchcraft Inc. EHHD15FF	15 HD, D-Sub, Female	Gender Changer	Gold	Panel Mount, Square Flange	Yellow	15 HD, D-Sub, Female	Nickel Silver, Tin Plated	1 Connector, 1 Flange, 1 Housing, 2 Screws	3

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Adapter Connector D-Sub, 15 HD, Female To D-Sub, 15 HD, Male Panel Mount, Square Flange
