EKM10-10-SCT
ActiveEaton - Electronics Division
FUSE EV 10A 1000VDC SCT TERM
EKM10-10-SCT
ActiveEaton - Electronics Division
FUSE EV 10A 1000VDC SCT TERM
Description
General part information
EKM10-10-SCT
10A 1 kVDC Fuse Cartridge Bolt Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | EKM10-10-SCT |
|---|---|
| Applications | Electrical, Industrial |
| Breaking Capacity | 50 kA |
| Current Rating | 10 A |
| DC Cold Resistance | 12.5 mOhms |
| Fuse Type | Cartridge |
| Mounting Type | Bolt Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Blade Terminal (Bolt), Cylindrical |
| Size / Dimension Diameter | 0.406 in |
| Size / Dimension Length | 1.535 in |
| Voltage Rating - DC | 1 kV |
