DD26M3P00S

Active

POSITRONIC

CONN D-SUB HD PLUG 26P VERT SLDR

Search across all available documentation for this part.

Active

POSITRONIC

CONN D-SUB HD PLUG 26P VERT SLDR

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	DD26M3P00S	DD26M Series

Color	Blue	Blue
Connector Style	High Density, D-Sub	High Density, D-Sub
Connector Type	Plug, Male Pins	Plug for Male Contacts, Plug, Male Pins
Contact Finish	Gold	Gold
Contact Finish Thickness	Flash	Flash
Contact Material	Copper Alloy	Copper Alloy
Contact Type	Signal	Signal
Current Rating (Amps)	5 A	5 A
Dielectric Material	Polyester, Glass Filled	Polyester, Glass Filled
Flange Feature	Housing/Shell (4-40)	Board Side, 4-40, Housing/Shell (4-40)
Ingress Protection	IP67, IP65	IP67, IP65
Material Flammability Rating	UL94 V-0	UL94 V-0
Mating Cycles	-	1000
Mounting Type	Through Hole	Free Hanging (In-Line), Through Hole
Note	-	Contacts Not Included
Number of Positions	26	26
Number of Rows	3	3
Operating Temperature [Max]	125 °C	125 °C
Operating Temperature [Min]	-55 °C	-55 °C
Shell Material, Finish	Stainless Steel, Passivated	Clear Chromate Plated Zinc, Steel, Stainless Steel, Passivated
Shell Size, Connector Layout	2	2
Shell Size, Connector Layout	(DA, A) High Density	(DA, A) High Density
Termination	Solder	Solder
Voltage Rating	300 VDC	300 VDC

CONN D-SUB HD HOUSING PLUG 26POS

Part	Shell Size, Connector Layout	Shell Size, Connector Layout	Note	Number of Positions	Contact Type	Connector Type	Number of Rows	Operating Temperature [Min]	Operating Temperature [Max]	Flange Feature	Dielectric Material	Connector Style	Ingress Protection	Shell Material, Finish	Color	Mating Cycles	Mounting Type	Contact Finish	Termination	Contact Material	Contact Finish Thickness	Voltage Rating	Material Flammability Rating	Current Rating (Amps)
POSITRONIC DD26M0S000	2	(DA, A) High Density	Contacts Not Included	26	Signal	Plug for Male Contacts	3	-55 °C	125 °C	4-40, Board Side	Polyester, Glass Filled	D-Sub, High Density	IP65, IP67	Clear Chromate Plated Zinc, Steel	Blue	1000	Free Hanging (In-Line)
POSITRONIC DD26M3P00S	2	(DA, A) High Density		26	Signal	Male Pins, Plug	3	-55 °C	125 °C	Housing/Shell (4-40)	Polyester, Glass Filled	D-Sub, High Density	IP65, IP67	Passivated, Stainless Steel	Blue		Through Hole	Gold	Solder	Copper Alloy	Flash	300 VDC	UL94 V-0	5 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

26 Position D-Sub, High Density Plug, Male Pins Connector
