VHV12-470S06P
ActiveVolgen + Furuno
2W 10V INPUT HIGH VOLTAGE DC/DC
Deep-Dive with AI
Search across all available documentation for this part.
VHV12-470S06P
ActiveVolgen + Furuno
2W 10V INPUT HIGH VOLTAGE DC/DC
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | VHV12-470S06P |
|---|---|
| Applications | ITE (Commercial) |
| Control Features | Active High, Enable |
| Current - Output (Max) [Max] | 5.6 mA |
| Features | OCP, Remote On/Off |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -10 °C |
| Power (Watts) | 2 W |
| Size / Dimension [x] | 110 mm |
| Size / Dimension [x] | 4.33 in |
| Size / Dimension [y] | 0.47 " |
| Size / Dimension [y] | 12 mm |
| Size / Dimension [z] | 0.78 in |
| Size / Dimension [z] | 19.8 mm |
| Type | High Voltage - Non-Isolated Module |
| Voltage - Input (Max) [Max] | 13.2 V |
| Voltage - Input (Min) [Min] | 10.8 V |
| Voltage - Output 1 | 470 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 215.16 | |
| 5 | $ 211.69 | |||
| 10 | $ 208.22 | |||
| 25 | $ 194.34 | |||
| 40 | $ 187.40 | |||
Description
General part information
VHV12-470S06P
High Voltage - Non-Isolated Module DC DC Converter 1 Output 470V 5.6mA 10.8V - 13.2V Input
Documents
Technical documentation and resources
No documents available
