E3FBAUSW
ActiveSwitchcraft Inc.
CONN PLUG FMALE XLR 3P SCREW
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
E3FBAUSW
ActiveSwitchcraft Inc.
CONN PLUG FMALE XLR 3P SCREW
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | E3FBAUSW | E3FBAU Series |
|---|---|---|
| Applications | Audio, Instrumentation | Audio, Instrumentation |
| Color | Black | Black |
| Connector Type | Female Sockets, Plug | Female Sockets, Plug |
| Contact Finish - Mating | Gold | Gold |
| Contact Material | Copper Alloy | Copper Alloy |
| Current Rating (Amps) | 15 A | 15 A |
| Fastening Type | Latch Lock | Latch Lock |
| Features | Ground | Ground |
| Insert Material | Thermoplastic | Thermoplastic |
| Mounting Feature | Flange | Flange |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -55 °C | -55 °C |
| Orientation | Keyed | Keyed |
| Primary Material | Metal | Metal |
| Shell Finish | Chrome | Chrome |
| Shell Material | Zinc Die Cast | Zinc Die Cast |
| Shell Size - Insert | XLR | XLR |
| Shielding | Shielded | Shielded |
| Termination | Screw | Screw |
E3FBAU Series
CONN PLUG FMALE XLR 3P SCREW
| Part | Color | Shell Material | Mounting Feature | Connector Type | Current Rating (Amps) | Shell Finish | Contact Finish - Mating | Contact Material | Shielding | Shell Size - Insert | Insert Material | Termination | Applications | Primary Material | Features | Fastening Type | Operating Temperature [Max] | Operating Temperature [Min] | Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Switchcraft Inc. E3FBAUSW | Black | Zinc Die Cast | Flange | Female Sockets, Plug | 15 A | Chrome | Gold | Copper Alloy | Shielded | XLR | Thermoplastic | Screw | Audio, Instrumentation | Metal | Ground | Latch Lock | 85 °C | -55 °C | Keyed |
Switchcraft Inc. E3FBAUSWEL | Black | Zinc Die Cast | Flange | Female Sockets, Plug | 15 A | Chrome | Gold | Copper Alloy | Shielded | XLR | Thermoplastic | Screw | Audio, Instrumentation | Metal | Ground | Latch Lock | 85 °C | -55 °C | Keyed |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 18.25 | |
| 10 | $ 14.05 | |||
| 25 | $ 12.71 | |||
Description
General part information
E3FBAU Series
3 Position Circular Connector Plug, Female Sockets Screw
