DCM152T450DE2B
ActiveCornell Dubilier Knowles
CAP ALUM 1.5MF 450V SCREW CHAS M
DCM152T450DE2B
ActiveCornell Dubilier Knowles
CAP ALUM 1.5MF 450V SCREW CHAS M
Description
General part information
DCM152T450DE2B
1.5 mF 450 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 75mOhm @ 120Hz
Technical Specifications
Parameters and characteristics for this part
| Specification | DCM152T450DE2B |
|---|---|
| Applications | General Purpose |
| Capacitance | 1.5 mF |
| ESR (Equivalent Series Resistance) | 75 mOhm |
| Height - Seated (Max) | 5.187 in |
| Lead Spacing | 1.25 in |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can - Screw Terminals, Radial |
| Polarization | Polar |
| Ripple Current | 11.3 A, 7.6 A |
| Size / Dimension Diameter | 3 in |
| Tolerance (Negative) | 10 % |
| Tolerance (Positive) | 50 % |
| Voltage - Rated | 450 V |
