10HV16B394KN

Active

KEMET

CAP CER 0.39UF 1KV X7R RADIAL

Search across all available documentation for this part.

Active

KEMET

CAP CER 0.39UF 1KV X7R RADIAL

Technical Specifications

Parameters and characteristics for this part

Specification	10HV16B394KN

Applications	Downhole
Capacitance	0.39 µF
Features	High Voltage, High Temperature
Height - Seated (Max) [Max] [z]	17.78 mm
Height - Seated (Max) [Max] [z]	0.7 "
Lead Spacing	0.7 in
Lead Spacing	17.78 mm
Lead Style	Straight
Mounting Type	Through Hole
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-55 °C
Package / Case	Radial
Size / Dimension [x]	0.82 "
Size / Dimension [x]	20.83 mm
Size / Dimension [y]	8.89 mm
Size / Dimension [y]	0.35 "
Temperature Coefficient	X7R
Tolerance	10 %
Voltage - Rated	1 kV
Voltage - Rated	1000 V

CAP CER 0.39UF 1KV X7R RADIAL

Part	Tolerance	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Temperature Coefficient	Capacitance	Applications	Lead Style	Voltage - Rated	Voltage - Rated	Lead Spacing	Lead Spacing	Mounting Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Features
KEMET 10HV16B394KN	10 %	Radial	-55 °C	200 °C	X7R	0.39 µF	Downhole	Straight	1 kV	1000 V	0.7 in	17.78 mm	Through Hole	8.89 mm	0.82 "	0.35 "	20.83 mm	17.78 mm	0.7 "	High Temperature, High Voltage

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

0.39 µF ±10% 1000V (1kV) Ceramic Capacitor X7R Radial
