Description
General part information
SG-710PHK 7.3728MM
7.3728 MHz XO (Standard) CMOS Oscillator 5V Enable/Disable 4-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | SG-710PHK 7.3728MM |
|---|---|
| Base Resonator | Crystal |
| Current - Supply (Disable) (Max) | 5 mA |
| Current - Supply (Max) | 15 mA |
| Frequency | 7.3728 MHz |
| Frequency Stability | 100 ppm |
| Function | Enable, Disable |
| Height - Seated (Max) | 0.055 in |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | CMOS |
| Package / Case | 4-SMD, No Lead |
| Package Length | 7.3 mm |
| Package Name | 4-SMD |
| Package Width | 4.8 mm |
| Size / Dimension Length | 0.287 in |
| Size / Dimension Width | 0.189 in |
| Type | XO (Standard) |
| Voltage - Supply | 5 VDC |
