Description
General part information
GL-2150C-10
Power Entry Connector Receptacle, Male Blades IEC 320-C14 Panel Mount, Flange
Technical Specifications
Parameters and characteristics for this part
| Specification | GL-2150C-10 |
|---|---|
| Accomodates a Fuse | No |
| Approval Agency | CSA, TUV, UL |
| Connector Style | IEC 320-C14 |
| Connector Type | Male Blades, Receptacle |
| Current Rating - Filter | 15 A |
| Features | Front or Rear Side Mount |
| Filter Application | Commercial |
| Filter Subtype | EMI, RFI |
| Filter Type | Filtered |
| Mounting Type | Panel Mount, Flange |
| Number of Positions | 3 |
| Panel Cutout Description | Variable Size |
| Termination | Solder Eyelet |
