1135349
ActivePhoenix Contact
SPT-THR 2 5/ 5-V-5 0 P26
1135349
ActivePhoenix Contact
SPT-THR 2 5/ 5-V-5 0 P26
Description
General part information
1135349
5 Position Wire to Board Terminal Block Vertical with Board 0.197" (5.00mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1135349 |
|---|---|
| Color | Black |
| Contact Material | Copper Alloy |
| Current | 20 A |
| Features | Push Button Actuated |
| Housing Material | Liquid Crystal Polymer, LCP |
| Mating Orientation | Vertical with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.197 in |
| Plating | Tin Plated |
| Positions Per Level | 5 |
| Voltage | 500 V |
| Wire Gauge (AWG) (Max) | 24 AWG |
| Wire Gauge (AWG) (Min) | 12 AWG |
| Wire Termination | Leg Spring, Screwless, Push-In Spring |
