AEVT60-C
ActiveAltran Magnetics, LLC
DC CONTACTOR 60A 24 VDC COIL
AEVT60-C
ActiveAltran Magnetics, LLC
DC CONTACTOR 60A 24 VDC COIL
Description
General part information
AEVT60-C
DC CONTACTOR 60A 24 VDC COIL
Technical Specifications
Parameters and characteristics for this part
| Specification | AEVT60-C |
|---|---|
| Coil Current | 250 mA |
| Coil Power | 5.2 W |
| Coil Resistance | 96 Ohms |
| Coil Voltage | 24 VDC |
| Contact Form | Form, X, 1, SPST-NO, DM |
| Contact Rating (Current) | 60 A |
| Mounting Type | Chassis Mount |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | 2 VDC |
| Operate Time | 30 ms |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Release Time | 10 ms |
| Switching Voltage DC (Max) | 750 VDC |
| Termination Style | Stud |
