737-406
ActiveWAGO Corporation
CONN TERMINAL BLOCK 18 POS 5.08MM SOLDER THRU-HOLE 21A BOX
737-406
ActiveWAGO Corporation
CONN TERMINAL BLOCK 18 POS 5.08MM SOLDER THRU-HOLE 21A BOX
Description
General part information
737-406
6 Position Wire to Board Terminal Block 45° (135°) Angle with Board 0.200" (5.08mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 737-406 |
|---|---|
| Clamp Material | Steel |
| Clamp Plating | Nickel Plated |
| Color | Orange |
| Contact Material | Electrolytic Copper |
| Current | 10 A |
| Housing Material | Nylon 6/6, Polyamide, PA66 |
| Mating Orientation (Angle) | 45 ° |
| Mating Orientation (Angle) (Alternate) | 135 ° |
| Mating Orientation (Description) | Angle with Board |
| Mounting Type | Through Hole |
| Number of Levels | 3 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -60 °C |
| Pitch | 5.08 mm |
| Plating | Tin Plated |
| Positions Per Level | 6 |
| Voltage | 300 V |
| Wire Gauge (AWG) (Max) | 28 AWG |
| Wire Gauge (AWG) (Min) | 12 AWG |
| Wire Termination | Spring Cage, Screwless, Tension Clamp |
