Y0937100K000B0L
ActiveVPG Foil Resistors
VSH2Z 100K00 0.1%
Y0937100K000B0L
ActiveVPG Foil Resistors
VSH2Z 100K00 0.1%
Description
General part information
Y0937100K000B0L
100 kOhms ±0.1% 0.3W Through Hole Resistor Radial Non-Inductive Metal Foil
Technical Specifications
Parameters and characteristics for this part
| Specification | Y0937100K000B0L |
|---|---|
| Composition | Metal Foil |
| Features | Non-Inductive |
| Height - Seated (Max) | 0.354 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -75 °C |
| Package / Case | Radial |
| Package Name | Radial |
| Power (Watts) | 300 mW |
| Resistance | 100 kOhm |
| Size / Dimension Length | 0.264 in |
| Size / Dimension Width | 0.109 in |
| Temperature Coefficient | 0.2 ppm/°C |
| Tolerance | 0.1 % |
