T4133512031-000
ActiveTE Connectivity AMP Connectors
CONN PLUG FMALE 3POS SOLDER CUP
Deep-Dive with AI
Search across all available documentation for this part.
T4133512031-000
ActiveTE Connectivity AMP Connectors
CONN PLUG FMALE 3POS SOLDER CUP
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | T4133512031-000 |
|---|---|
| Applications | Industrial |
| Color | Silver |
| Connector Type | Female Sockets, Plug |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 3 µin |
| Contact Finish Thickness - Mating | 0.076 µm |
| Contact Material | Copper Alloy |
| Current Rating (Amps) | 4 A |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Insert Material | Polyamide (PA66), Nylon 6/6 |
| Material Flammability Rating | UL94 V-0 |
| Mounting Feature | Bulkhead - Rear Side Nut |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Orientation | D |
| Primary Material | Metal |
| Shell Finish | Nickel |
| Shell Material | Copper Alloy |
| Shell Size - Insert | M12-3 |
| Shielding | Unshielded |
| Voltage Rating | 250 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 4.60 | |
| 10 | $ 4.03 | |||
| 100 | $ 3.61 | |||
| 1000 | $ 3.00 | |||
T41335 Series
CONN PLUG FMALE 3POS SOLDER CUP
| Part | Material Flammability Rating | Applications | Shell Material | Voltage Rating | Shell Size - Insert | Primary Material | Insert Material | Shielding | Orientation | Ingress Protection | Contact Finish - Mating | Mounting Feature | Shell Finish | Connector Type | Current Rating (Amps) | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors T4133512031-000 | UL94 V-0 | Industrial | Copper Alloy | 250 VDC | M12-3 | Metal | Polyamide (PA66), Nylon 6/6 | Unshielded | D | IP67 - Dust Tight, Waterproof | Gold | Bulkhead - Rear Side Nut | Nickel | Female Sockets, Plug | 4 A | 85 °C | -40 °C | Copper Alloy | 3 µin | 0.076 µm | Silver |
Description
General part information
T41335 Series
3 Position Circular Connector Plug, Female Sockets Solder Cup
