CXP-3R0156R-TW
ActiveCDA (Zhifengwei Technology)
3.0V 15F 12.5X25 EDLC
CXP-3R0156R-TW
ActiveCDA (Zhifengwei Technology)
3.0V 15F 12.5X25 EDLC
Description
General part information
CXP-3R0156R-TW
15 F (EDLC) Supercapacitor 3 V Radial, Can 30mOhm @ 1kHz 1000 Hrs @ 85°C
Technical Specifications
Parameters and characteristics for this part
| Specification | CXP-3R0156R-TW |
|---|---|
| Capacitance | 15 F |
| ESR (Equivalent Series Resistance) | 30 mOhm |
| Height - Seated (Max) | 1.043 in |
| Lead Spacing | 0.197 in |
| Lifetime | 1000 Hrs, 1000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 65 °C, 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can, Radial |
| Size / Dimension Diameter | 0.492 in |
| Termination | PC Pins |
| Tolerance (Negative) | 10 % |
| Tolerance (Positive) | 30 % |
| Voltage - Rated | 3 VDC |
