1892916

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 2 POS 5MM PITCH FEED THROUGH HEADER

Search across all available documentation for this part.

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 2 POS 5MM PITCH FEED THROUGH HEADER

Technical Specifications

Parameters and characteristics commom to parts in this series

Pluggable Terminal Blocks 15 Pos 5mm pitch Feed Through Header

Part	Rear Panel Wire Connection	Rear Panel Wire Connection	Rear Panel Wire Connection	Positions Per Level	Current - UL	Features	Color	Panel Thickness [Min]	Panel Thickness [Max]	Panel Thickness [Max]	Panel Thickness [Min]	Voltage - UL	Number of Levels	Panel Mount Type	Width	Width	Front Panel Wire Connection	Pitch [x]	Pitch [x]	Width [x]	Width [x]
Phoenix Contact 1892916	0.11 in	Quick Connect, Solder Eyelet	2.8 mm	2	10 A	Lock Opening	Black	0.02 "	4 mm	0.157 in	0.5 mm	300 V	1	Screw Mount - Front Flange	30 mm	1.181 in	Header, Male Pins	5 mm	0.197 in
Phoenix Contact 0710138	0.11 in	Quick Connect, Solder Eyelet	2.8 mm	13	10 A		Green	0.02 "	4 mm	0.157 in	0.5 mm	300 V	1	Screw Mount - Front Flange	85 mm	3.346 in	Header, Male Pins	5 mm	0.197 in
Phoenix Contact 0707358	0.11 in	Quick Connect, Solder Eyelet	2.8 mm	14		Lock Opening	Green	0.02 "	4 mm	0.157 in	0.5 mm	300 V	1	Screw Mount - Front Flange			Header, Male Pins	5.08 mm	0.2 in	91.44 mm	3.6 in
Phoenix Contact 0710154	0.11 in	Quick Connect, Solder Eyelet	2.8 mm	15	10 A		Green	0.02 "	4 mm	0.157 in	0.5 mm	300 V	1	Screw Mount - Front Flange			Header, Male Pins	5 mm	0.197 in	95 mm	3.74 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pluggable Terminal Blocks 15 Pos 5mm pitch Feed Through Header
