B41042A7567M
ObsoleteEPCOS - TDK Electronics
CAP ALUM 560UF 20% 35V RADIAL
B41042A7567M
ObsoleteEPCOS - TDK Electronics
CAP ALUM 560UF 20% 35V RADIAL
Description
General part information
B41042A7567M
560 µF 35 V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C
Technical Specifications
Parameters and characteristics for this part
| Specification | B41042A7567M |
|---|---|
| Applications | General Purpose |
| Capacitance | 560 µF |
| Height - Seated (Max) | 0.866 in |
| Impedance | 100 mOhm |
| Lead Spacing | 0.197 in |
| Lifetime | 5000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Can, Radial |
| Polarization | Polar |
| Ripple Current | 1.145 A, 1.431 A |
| Size / Dimension Diameter | 0.492 in |
| Tolerance | 20 % |
| Voltage - Rated | 35 V |
