Description
General part information
DPD050055-P13P-TC
5V 2.5 W AC/DC External Wall Mount (Class II) Adapter Fixed Blade Input
Technical Specifications
Parameters and characteristics for this part
| Specification | DPD050055-P13P-TC |
|---|---|
| Applications | ITE (Commercial) |
| Cord Length | 72 in |
| Current - Output (Max) | 500 mA |
| Form | Wall Mount (Class II) |
| Input Connector | NEMA 1-15P |
| Input Type | Fixed Blade |
| Output Connector | Barrel Plug |
| Output Connector I.D. | 1.7 mm |
| Output Connector Length | 9.5 mm |
| Output Connector O.D. | 4 mm |
| Polarization | Positive Center |
| Power (Watts) | 2.5 W |
| Region Utilized | North America |
| Size / Dimension Height | 1.56 in |
| Size / Dimension Length | 2.32 in |
| Size / Dimension Width | 1.77 in |
| Voltage - Input | 120 VAC |
| Voltage - Output | 5 VDC |
