SI5368A-C-GQR
LTBSkyworks Solutions Inc.
CLOCK GENERATOR 0.002MHZ TO 710MHZ-IN 1417MHZ-OUT 100-PIN TQFP T/R
SI5368A-C-GQR
LTBSkyworks Solutions Inc.
CLOCK GENERATOR 0.002MHZ TO 710MHZ-IN 1417MHZ-OUT 100-PIN TQFP T/R
Description
General part information
SI5368A-C-GQR
CLOCK GENERATOR 0.002MHZ TO 710MHZ-IN 1417MHZ-OUT 100-PIN TQFP T/R
Technical Specifications
Parameters and characteristics for this part
| Specification | SI5368A-C-GQR |
|---|---|
| Differential Input | Yes |
| Differential Output | Yes |
| Divider | No |
| Frequency - Max | 1.42 GHz |
| Input | Clock |
| Input Ratio | 4 |
| Mounting Type | Surface Mount |
| Multiplier | Yes |
| Number of Circuits | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | LVDS, LVPECL, LVCMOS, CML |
| Output Ratio | 5 |
| Package / Case | 100-TQFP |
| Package Length | 14 mm |
| Package Name | 100-TQFP |
| Package Width | 14 mm |
| PLL | Yes |
| Type | Clock Multiplier, Jitter Attenuator |
| Voltage - Supply (Maximum) | 3.63 V |
| Voltage - Supply (Minimum) | 1.71 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
