A15-60CS
ActiveCentury Spring Corp
COMP O= .484,L= 1.28,W= .067
A15-60CS
ActiveCentury Spring Corp
COMP O= .484,L= 1.28,W= .067
Description
General part information
A15 Series
COMP O= .484,L= 1.28,W= .067
Technical Specifications
Parameters and characteristics for this part
| Specification | A15-60CS |
|---|---|
| Diameter - Inside | 0.35 in |
| Diameter - Outside | 0.484 in |
| End Style | Ground, Closed |
| Finish | None |
| Free Length | 1.28 in |
| Material | Stainless Steel |
| Rate (lbs/in) | 55 lbs/in |
| Type | Compression |
| Wire Diameter | 0.067 in |
