CDBH3-00340-HF

Active

Comchip Technology

DIODE ARR SCHOTT 40V 30MA SOT523

Search across all available documentation for this part.

Active

Comchip Technology

DIODE ARR SCHOTT 40V 30MA SOT523

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	CDBH3-00340-HF	CDBH3-00340 Series

Current - Average Rectified (Io) (per Diode)	30 mA	30 mA
Current - Reverse Leakage @ Vr	1 µA	1 µA
Diode Configuration	1 Pair Common Cathode	1 Pair Common Cathode
Mounting Type	Surface Mount	Surface Mount
Operating Temperature - Junction	125 °C	125 °C
Package / Case	SOT-523	SOT-523
Speed	Any Speed	Any Speed
Speed	200 mA	200 mA
Supplier Device Package	SOT-523	SOT-523
Technology	Schottky	Schottky
Voltage - DC Reverse (Vr) (Max) [Max]	40 V	40 V
Voltage - Forward (Vf) (Max) @ If	370 mV	370 mV

DIODE ARR SCHOTT 40V 30MA SOT523

Part	Speed	Speed	Operating Temperature - Junction	Diode Configuration	Voltage - Forward (Vf) (Max) @ If	Supplier Device Package	Technology	Voltage - DC Reverse (Vr) (Max) [Max]	Current - Reverse Leakage @ Vr	Current - Average Rectified (Io) (per Diode)	Package / Case	Mounting Type
Comchip Technology CDBH3-00340-G	Any Speed	200 mA	125 °C	1 Pair Common Cathode	370 mV	SOT-523	Schottky	40 V	1 µA	30 mA	SOT-523	Surface Mount
Comchip Technology CDBH3-00340-HF	Any Speed	200 mA	125 °C	1 Pair Common Cathode	370 mV	SOT-523	Schottky	40 V	1 µA	30 mA	SOT-523	Surface Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Diode Array 1 Pair Common Cathode 40 V 30mA Surface Mount SOT-523

Technical documentation and resources

No documents available
