0.8FH,R13H.5,060,08/Sn,TR,SC-5084616-2

5084616-2

Active
TE Connectivity AMP Connectors

BOARD TO BOARD & MEZZANINE CONNECTORS 0.8MM-13H REC 2X030P 400

Find alt
0.8FH,R13H.5,060,08/Sn,TR,SC-5084616-2

5084616-2

Active
TE Connectivity AMP Connectors

BOARD TO BOARD & MEZZANINE CONNECTORS 0.8MM-13H REC 2X030P 400

Find alt

Description

General part information

1 mm Free Height Series

PCB Mount Receptacle, Vertical, Board-to-Board, 60 Position, .8 mm [.031 in] Centerline, Gold (Au), Surface Mount, Signal, Natural, Free Height

Technical Specifications

Parameters and characteristics for this part

Specification5084616-2
Connector TypeOuter Shroud Contacts, Receptacle
Contact FinishGold
Contact Finish Thickness8 µin
FeaturesBoard Guide
Height Above Board0.463 in
Mated Stacking Height Options15mm, 16mm, 14mm, 13mm
Mounting TypeSurface Mount
Number of Positions60
Number of Rows2
Pitch0.031 in
