QR/P Series

Part	Note	Number of Rows	Color	Pitch	Connector Type	Number of Positions	Features	Mounting Type	Connector Usage	Connector Style
Hirose Electric Co Ltd QR/P4-24P-C(21)	Contacts Not Included	2	Blue	0.1 in	Housing for Male Pins	24 pos	Guide Pin	Panel Mount	Plug	Rack and Panel
Hirose Electric Co Ltd QR/P4-16S-C(21)	Contacts Not Included	2	Blue	0.1 in	Housing for Female Sockets	16	Mating Guide	Panel Mount	Receptacle	Rack and Panel
Hirose Electric Co Ltd QR/P4-24P-C(26)	Contacts Not Included	2	Black	0.1 in	Housing for Male Pins	24 pos	Guide Pin	Panel Mount	Plug	Rack and Panel
Hirose Electric Co Ltd QR/P-8P-C(01)	Contacts Not Included	2	Blue	0.177 in	Housing for Male Pins	8	Guide Pin	Panel Mount	Plug	Rack and Panel
Hirose Electric Co Ltd QR/P-12P-C(21)	Contacts Not Included	2	Blue	0.177 in	Housing for Male Pins	12	Guide Pin	Panel Mount	Plug	Rack and Panel
Hirose Electric Co Ltd QR/P4-8P-C(21)	Contacts Not Included	2	Black	0.1 in	Housing for Male Pins	8	Guide Pin	Panel Mount	Plug	Rack and Panel
Hirose Electric Co Ltd QR/P4-12S-C(21)	Contacts Not Included	2	Black	0.1 in	Housing for Female Sockets	12	Mating Guide	Panel Mount	Receptacle	Rack and Panel
Hirose Electric Co Ltd QR/P-12S-C(21)	Contacts Not Included	2	Blue	0.177 in	Housing for Female Sockets	12	Mating Guide	Panel Mount	Receptacle	Rack and Panel
Hirose Electric Co Ltd QR/P4-32P-C(26)	Contacts Not Included	2	Black	0.1 in	Housing for Male Pins	32	Guide Pin	Panel Mount	Plug	Rack and Panel
Hirose Electric Co Ltd QR/P-16P-C(01)	Contacts Not Included	2	Blue	0.177 in	Housing for Male Pins	16	Guide Pin	Panel Mount	Plug	Rack and Panel
