Specification	JA3D-C1001138

Color	Natural
Density	1.05 g/cm³
Features	Elastomeric, Wear & Friction
Filament Diameter	0.112 in
Filament Material	TPE (Thermoplastic Elastomer)
Operating Temperature (Max)	270 °C
Operating Temperature (Min)	230 °C
Tensile Strength	11 Mpa

JA3D Series

Part	Filament Material	Color	Operating Temperature (Min)	Operating Temperature (Max)	Filament Diameter	Features	Density (Min)	Density (Max)	Tensile Strength	Flex Strength	Density
Jabil Inc. JA3D-C1001032	PETG (Polyethylene Terephthalate Glycol-modified)	Natural	240 °C	250 °C	0.07 in
Jabil Inc. JA3D-C1001068	ABS (Acrylonitrile Butadiene Styrene)	Black	275 °C	295 °C	0.07 in	Reinforced	1.1 g/cm³	1.12 g/cm³	35.3 Mpa	59.8 Mpa
Jabil Inc. JA3D-C1001031	TPU (Thermoplastic Polyurethane)	Natural	220 °C	230 °C	0.112 in	Elastomeric Wear & Friction					1.2 g/cm³
Jabil Inc. JA3D-C1001317	PA (Polyamide)	Blue			0.112 in
Jabil Inc. JA3D-C1001029	PETG (Polyethylene Terephthalate Glycol-modified)	Natural	240 °C	250 °C	0.112 in						1.24 g/cm³
Jabil Inc. JA3D-C1001055	ABS (Acrylonitrile Butadiene Styrene)	Natural	275 °C	295 °C	0.112 in	Reinforced	1.1 g/cm³	1.12 g/cm³	35.3 Mpa	59.8 Mpa
Jabil Inc. JA3D-C1001073	PC (Polycarbonate)	Black	285 °C	305 °C	0.07 in	Flame-Retardant Wear & Friction			61 Mpa	93.9 Mpa	1.18 g/cm³
Jabil Inc. JA3D-C1001135	TPE (Thermoplastic Elastomer)	Black	240 °C	250 °C	0.112 in	Elastomeric Wear & Friction			6 Mpa		1.05 g/cm³
Jabil Inc. JA3D-C1001059	PC (Polycarbonate)	Natural	285 °C	305 °C	0.112 in	Flame-Retardant Wear & Friction			61 Mpa	93.9 Mpa	1.18 g/cm³
Jabil Inc. JA3D-C1001058	PC (Polycarbonate)	Natural	285 °C	305 °C	0.07 in	Flame-Retardant Wear & Friction			61 Mpa	93.9 Mpa	1.18 g/cm³
