1775871
ObsoletePhoenix Contact
CONN BASE BOTTOM ENTRY SZD50
1775871
ObsoletePhoenix Contact
CONN BASE BOTTOM ENTRY SZD50
Description
General part information
1775871
Base - Panel Mount Connector Bottom Entry D50 IP65 - Dust Tight, Water Resistant
Technical Specifications
Parameters and characteristics for this part
| Specification | 1775871 |
|---|---|
| Connector Type | Base - Panel Mount |
| Housing Color | Gray |
| Housing Finish | Powder Coated |
| Housing Material | Die Cast, Aluminum |
| Ingress Protection Description | Dust Tight, Water Resistant |
| Ingress Protection IP Rating | IP65 |
| Lock Location | Locking Clip (2) on Hood |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Size | D50 |
| Size / Dimension Height | 1.102 in |
| Size / Dimension Length | 4.016 in |
| Size / Dimension Width | 2.244 in |
| Style | Bottom Entry |
