ATSAMA5 Series

Part	Ethernet Ports	Ethernet Speed Options	Package Name	Package Length	Package Width	Additional Interfaces	Security Features	Speed	Co-Processors/DSP	Package / Case	Voltage - I/O	Operating Temperature (Max)	Operating Temperature (Min)	Core Processor	RAM Controllers	Mounting Type	USB	Bus Width	Number of Cores	Display & Interface Controllers	Graphics Acceleration
Microchip Technology ATSAMA5D225C-D1M-CUR	1	100Mbps 10Mbps	196-TFBGA	11 mm	11 mm	I2C QSPI SMC SPI UART USART	ARM TZ Boot Security Cryptography RTIC Secure Fusebox Secure JTAG Secure Memory Secure RTC	500 MHz	Multimedia NEON™ MPE	196-TFBGA CSBGA	3.3 V	85 °C	-40 °C	ARM® Cortex®-A5	DDR2 DDR3 DDR3L LPDDR1 LPDDR2 LPDDR3 QSPI	Surface Mount	USB 2.0 + HSIC	32 Bit	1 Core	Keyboard LCD Touchscreen	Yes

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
