B78108S1225K000
ActiveEPCOS - TDK Electronics
FIXED IND 2.2MH 80MA 34.7 OHM TH
B78108S1225K000
ActiveEPCOS - TDK Electronics
FIXED IND 2.2MH 80MA 34.7 OHM TH
Description
General part information
B78108S1225K000
2.2 mH Unshielded Drum Core, Wirewound Inductor 80 mA 34.7Ohm Max Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | B78108S1225K000 |
|---|---|
| Current Rating | 0.08 A |
| DC Resistance (DCR) (Max) | 34.7 Ohm |
| Frequency - Self Resonant | 1.1 MHz |
| Inductance | 2.2 mH |
| Inductance Frequency - Test | 252 kHz |
| Material - Core | Ferrite |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Q | 40 |
| Shielding | Unshielded |
| Size / Dimension Diameter | 0.157 in |
| Size / Dimension Length | 0.362 in |
| Tolerance | 10 % |
| Type | Drum Core, Wirewound |
