1SNG618006R0000
ActiveTE Connectivity AMP Connectors
CABLE GLANDS, STRAIN RELIEFS & CORD GRIPS EP-RJG-M20-BL-B
1SNG618006R0000
ActiveTE Connectivity AMP Connectors
CABLE GLANDS, STRAIN RELIEFS & CORD GRIPS EP-RJG-M20-BL-B
Description
General part information
1SNG618006R0000
Cable Gland, RJ45 Type, PA 6, 3 – 6 mm Clamping Range, Black, IP68
Technical Specifications
Parameters and characteristics for this part
| Specification | 1SNG618006R0000 |
|---|---|
| Color | Black |
| Ingress Protection Description | Dust Tight, Waterproof |
| Ingress Protection IP Rating | IP68 |
| Material | Polyamide (PA6), Nylon 6 |
| Operating Temperature (Max) | 100 °C |
| Operating Temperature (Min) | -20 °C |
| Outside Cable Diameter (Max) | 0.236 in |
| Outside Cable Diameter (Min) | 0.118 in |
| Panel Hole Size | 1.217 in |
| Thread Diameter | 20 mm |
| Thread Length | 0.591 in |
| Thread Pitch | 1.5 mm |
| Type | Cable Gland |
