AC05000003000JAC00
ActiveVishay Dale
THROUGH HOLE RESISTOR, 300 OHM, AC SERIES, 5 W, ± 5%, AXIAL LEADED, 39 V
AC05000003000JAC00
ActiveVishay Dale
THROUGH HOLE RESISTOR, 300 OHM, AC SERIES, 5 W, ± 5%, AXIAL LEADED, 39 V
Description
General part information
AC Series
300 Ohms ±5% 5W Through Hole Resistor Axial Flame Retardant Coating, Pulse Withstanding, Safety Wirewound
Technical Specifications
Parameters and characteristics for this part
| Specification | AC05000003000JAC00 |
|---|---|
| Composition | Wirewound |
| Features | Pulse Withstanding, Safety, Flame Retardant Coating |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 275 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Axial |
| Package Name | Axial |
| Power (Watts) | 5 W |
| Resistance | 300 Ohm |
| Size / Dimension Diameter | 0.295 in |
| Size / Dimension Length | 0.709 in |
| Temperature Coefficient (Highest) | -10 ppm/°C |
| Temperature Coefficient (Lowest) | -80 ppm/°C |
| Tolerance | 5 % |
