BSH1402P11A2A
ActiveSCHNEIDER ELECTRIC
MOTOR 140 IP40 KEYED INC NOBRK A
BSH1402P11A2A
ActiveSCHNEIDER ELECTRIC
MOTOR 140 IP40 KEYED INC NOBRK A
Description
General part information
BSH1402P11A2A
AC Motor Servomotor 4000 RPM 3.4kW 480VAC
Technical Specifications
Parameters and characteristics for this part
| Specification | BSH1402P11A2A |
|---|---|
| Diameter - Shaft | 0.945 in |
| Function | Servomotor |
| Length - Shaft and Bearing | 1.969 in |
| Mounting Hole Spacing | 5.118 in |
| Power - Rated | 3.4 kW |
| RPM | 4000 RPM |
| Size / Dimension Length | 5.512 in |
| Size / Dimension Shape | Square |
| Size / Dimension Width | 5.512 in |
| Termination Style | Connector |
| Torque - Rated (mNm) | 15000 mNm |
| Torque - Rated (oz-in) | 2124 oz-in |
| Type | AC Motor |
| Voltage - Rated | 480 VAC |
