SRP1265C-6R8M
ObsoleteBourns Inc.
FIXED IND 6.8UH 15A 13.2MOHM SMD
SRP1265C-6R8M
ObsoleteBourns Inc.
FIXED IND 6.8UH 15A 13.2MOHM SMD
Description
General part information
SRP1265C-6R8M
6.8 µH Shielded Inductor 15 A 13.2mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | SRP1265C-6R8M |
|---|---|
| Current - Saturation (Isat) | 25 A |
| Current Rating | 15 A |
| DC Resistance (DCR) (Max) | 13.2 mOhm |
| Frequency - Self Resonant | 14 MHz |
| Height - Seated (Max) | 0.256 in |
| Inductance | 6.8 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Metal |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Q | 20 |
| Shielding | Shielded |
| Size / Dimension Length | 0.531 in |
| Size / Dimension Width | 0.496 in |
| Tolerance | 20 % |
