AD9886KS-100
ActiveAnalog Devices Inc./Maxim Integrated
TRIPLE ADC, 8-BIT PARALLEL
AD9886KS-100
ActiveAnalog Devices Inc./Maxim Integrated
TRIPLE ADC, 8-BIT PARALLEL
Description
General part information
AD9886KS-100
8 Bit Analog to Digital Converter 8 Input 3 Pipelined 160-MQFP (28x28)
Technical Specifications
Parameters and characteristics for this part
| Specification | AD9886KS-100 |
|---|---|
| Architecture | Pipelined |
| Configuration | ADC |
| Data Interface | Serial |
| Mounting Type | Surface Mount |
| Number of A/D Converters | 3 count |
| Number of Bits | 8 bits |
| Number of Inputs | 8 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | 0 °C |
| Package / Case | 160-BQFP |
| Package Length | 28 mm |
| Package Name | 160-MQFP |
| Package Width | 28 mm |
| Ratio - ADC | 3 |
| Ratio - S/H | 0 |
| Reference Type | Internal |
| Voltage - Supply, Analog (Max) | 3.6 V |
| Voltage - Supply, Analog (Min) | 3 V |
| Voltage - Supply, Analog (Typical) | 2.2 V |
| Voltage - Supply, Digital (Nominal) | 2.2 V |
| Voltage - Supply, Digital (Range 1) Maximum | 3.6 V |
| Voltage - Supply, Digital (Range 1) Minimum | 3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
