Specification	XPEGRN-L1-0000-00B03

Color	Green
Current - Max	1 A
Current - Test	350 mA
Height - Seated (Max)	0.084 in
Lumens/Watt	84 lm/W
Luminous Flux	97 lm
Luminous Flux (Maximum)	100 lm
Luminous Flux (Minimum)	94 lm
Mounting Type	Surface Mount
Package / Case	1414 (3535 Metric)
Package Name	SMD
Size / Dimension Length	0.136 in
Size / Dimension Width	0.136 in
Temperature - Test	25 °C
Thermal Resistance of Package	15 °C/W
Viewing Angle	130 °
Voltage - Forward (Vf) (Typ)	3.4 V
Wavelength	530 nm
Wavelength (Maximum)	535 nm
Wavelength (Minimum)	525 nm
Wavelength (Nominal)	530 nm

XPEGRN Series

Part	Thermal Resistance of Package	Voltage - Forward (Vf) (Typ)	Package / Case	Current - Max	Package Name	Color	Height - Seated (Max)	Current - Test	Temperature - Test	Mounting Type	Size / Dimension Length	Size / Dimension Width	Lumens/Watt	Luminous Flux	Luminous Flux (Maximum)	Luminous Flux (Minimum)	Viewing Angle	Wavelength	Wavelength (Minimum)	Wavelength (Maximum)	Wavelength (Nominal)
CreeLED, Inc. XPEGRN-L1-R250-00803	15 °C/W	3.4 V	1414 (3535 Metric)	1 A	SMD	Green	0.084 in	350 mA	25 °C	Surface Mount	0.136 in	0.136 in	67 lm/W	77 lm	81 lm	74 lm	130 °
CreeLED, Inc. XPEGRN-L1-R250-00902		3.4 V	1414 (3535 Metric)	1 A	SMD	Green	0.084 in	350 mA	25 °C	Surface Mount	0.136 in	0.136 in	73 lm/W	84 lm	87 lm	81 lm	130 °	525 nm	520 nm	530 nm	525 nm
CreeLED, Inc. XPEGRN-L1-0000-00C01		3.4 V	1414 (3535 Metric)	1 A	SMD	Green	0.084 in	350 mA	25 °C	Surface Mount	0.136 in	0.136 in	90 lm/W	104 lm	107 lm	100 lm	130 °	528 nm	520 nm	535 nm	528 nm
CreeLED, Inc. XPEGRN-L1-R250-00801	15 °C/W	3.4 V	1414 (3535 Metric)	1 A	SMD	Green	0.084 in	350 mA	25 °C	Surface Mount	0.136 in	0.136 in	67 lm/W	77 lm	81 lm	74 lm	130 °
CreeLED, Inc. XPEGRN-L1-0000-00A02	15 °C/W	3.4 V	1414 (3535 Metric)	1 A	SMD	Green	0.084 in	350 mA	25 °C	Surface Mount	0.136 in	0.136 in	79 lm/W	91 lm	94 lm	87 lm	130 °	525 nm	520 nm	530 nm	525 nm
CreeLED, Inc. XPEGRN-L1-R250-00E01	15 °C/W	3.3 V	1414 (3535 Metric)	1 A	SMD	Green	0.084 in	350 mA	25 °C	Surface Mount	0.136 in	0.136 in	102 lm/W	118 lm	122 lm	114 lm	130 °	528 nm	520 nm	535 nm	528 nm
CreeLED, Inc. XPEGRN-L1-0000-00803	15 °C/W	3.4 V	1414 (3535 Metric)	1 A	SMD	Green	0.084 in	350 mA	25 °C	Surface Mount	0.136 in	0.136 in	67 lm/W	77 lm	81 lm	74 lm	130 °
CreeLED, Inc. XPEGRN-L1-R250-00D02	15 °C/W	3.3 V	1414 (3535 Metric)	1 A	SMD	Green	0.084 in	350 mA	25 °C	Surface Mount	0.136 in	0.136 in	96 lm/W	111 lm	114 lm	107 lm	130 °	525 nm	520 nm	530 nm	525 nm
CreeLED, Inc. XPEGRN-L1-R250-00D01	15 °C/W	3.4 V	1414 (3535 Metric)	1 A	SMD	Green	0.084 in	350 mA	25 °C	Surface Mount	0.136 in	0.136 in	96 lm/W	111 lm	114 lm	107 lm	130 °	528 nm	520 nm	535 nm	528 nm
CreeLED, Inc. XPEGRN-L1-R250-00B02	15 °C/W	3.4 V	1414 (3535 Metric)	1 A	SMD	Green	0.084 in	350 mA	25 °C	Surface Mount	0.136 in	0.136 in	84 lm/W	97 lm	100 lm	94 lm	130 °	525 nm	520 nm	530 nm	525 nm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

Datasheet

XPEGRN-L1-0000-00B03 | Datasheet
