FWPQ2817H-100K
ActiveAllied Components International
10UH +/-10% FLAT WIRE SMD POWER
FWPQ2817H-100K
ActiveAllied Components International
10UH +/-10% FLAT WIRE SMD POWER
Description
General part information
FWPQ2817H-100K
10 µH Shielded Wirewound Inductor 28 A 2.82mOhm 2-SMD, Gull Wing
Technical Specifications
Parameters and characteristics for this part
| Specification | FWPQ2817H-100K |
|---|---|
| Current - Saturation (Isat) | 32.1 A |
| Current Rating | 28 A |
| DC Resistance (DCR) | 2.82 mOhm |
| Frequency - Self Resonant | 20 MHz |
| Height - Seated (Max) | 0.669 in |
| Inductance | 10 µH |
| Inductance Frequency - Test | 500 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Gull Wing, 2-SMD |
| Package Name | 2-SMD |
| Shielding | Shielded |
| Size / Dimension Length | 1.102 in |
| Size / Dimension Width | 0.76 in |
| Tolerance | 10 % |
| Type | Wirewound |
