AEV31024
ObsoletePanasonic Electronic Components
RELAY AUTOMOTIVE SPST 10A 24V
AEV31024
ObsoletePanasonic Electronic Components
RELAY AUTOMOTIVE SPST 10A 24V
Description
General part information
AEV31024
RELAY AUTOMOTIVE SPST 10A 24V
Technical Specifications
Parameters and characteristics for this part
| Specification | AEV31024 |
|---|---|
| Coil Current | 52 mA |
| Coil Power | 1.24 W |
| Coil Type | Non Latching |
| Coil Voltage | 24 VDC |
| Contact Form | SPST-NO |
| Contact Rating (Current) | 10 A |
| Form A Count | 1 |
| Mounting Type | Through Hole |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | 2 VDC |
| Operate Time | 50 ms |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -40 °C |
| Release Time | 30 ms |
| Switching Voltage (Nominal) | 400 VDC |
| Termination Style | PC Pin |
