Description
General part information
E32D630HPN224MEM9M
ALUMINUM ELECTROLYTIC CAPACITORS
Technical Specifications
Parameters and characteristics for this part
| Specification | E32D630HPN224MEM9M |
|---|---|
| Applications | General Purpose |
| Capacitance | 220000 µF |
| ESR (Equivalent Series Resistance) | 4 mOhm |
| Lifetime | 2000 Hrs |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can - Screw Terminals, Radial |
| Polarization | Polar |
| Ripple Current | 53.86 A, 60.32 A |
| Size / Dimension Diameter | 3 in |
| Tolerance | 20 % |
| Voltage - Rated | 63 V |
