Specification	SQT-108-01-S-D

Connector Type	Receptacle
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	30 µin
Contact Length - Post	0.09 in
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Forked
Current Rating (Per Contact)	5.1 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.25 in
Insulation Material	Liquid Crystal Polymer (LCP)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	16
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-55 °C
Pitch - Mating	0.079 in
Row Spacing - Mating	0.079 in
Style	Board, Board or Cable
Termination	Solder

SQT Series

...

Part	Material Flammability Rating	Insulation Height	Mounting Type	Contact Finish Thickness - Mating	Pitch - Mating	Operating Temperature (Max)	Operating Temperature (Min)	Insulation Color	Termination	Contact Type	Fastening Type	Contact Finish - Mating	Number of Rows	Contact Finish - Post	Number of Positions	Row Spacing - Mating	Contact Length - Post	Connector Type	Current Rating (Per Contact)	Number of Positions Loaded	Style	Contact Finish Thickness - Mating	Contact Material	Contact Shape	Insulation Material	Contact Finish Thickness - Post
Samtec Inc. SQT-108-01-L-5	UL94 V-0	0.25 in	Through Hole	10 µin	0.079 in	125 °C	-55 °C	Black	Solder	Forked	Push-Pull	Gold	5	Tin	40	0.079 in	0.09 in	Receptacle	5.1 A	All	Board Board or Cable
Samtec Inc. SQT-105-01-S-D	UL94 V-0	0.25 in	Through Hole	30 µin	0.079 in	125 °C	-55 °C	Black	Solder	Forked	Push-Pull	Gold	2	Tin	10	0.079 in	0.09 in	Receptacle	5.1 A	All	Board Board or Cable
Samtec Inc. SQT-105-01-F-T-RA	UL94 V-0	0.236 in	Right Angle Through Hole		0.079 in	125 °C	-55 °C	Black	Solder	Forked	Push-Pull	Gold	3	Tin	15	0.079 in	0.09 in	Receptacle	5.1 A	All	Board Board or Cable	Flash	Phosphor Bronze	Square	Liquid Crystal Polymer (LCP)
Samtec Inc. SQT-134-02-G-D	UL94 V-0	0.25 in	Through Hole	20 Ąin	0.079 in	125 °C	-55 °C	Black	Solder	Forked	Push-Pull	Gold	2	Gold	68	0.079 in	0.6 in	Receptacle	5.1 A	All	Board Board or Cable		Phosphor Bronze	Square	Liquid Crystal Polymer (LCP)	3 µin
Samtec Inc. SQT-126-01-L-T-RA	UL94 V-0	0.236 in	Right Angle Through Hole	10 µin	0.079 in	125 °C	-55 °C	Black	Solder	Forked	Push-Pull	Gold	3	Tin	78	0.079 in	0.09 in	Receptacle	5.1 A	All	Board Board or Cable		Phosphor Bronze	Square	Liquid Crystal Polymer (LCP)
Samtec Inc. SQT-104-01-LM-S-RA	UL94 V-0	0.079 in	Right Angle Through Hole	10 µin	0.079 in	125 °C	-55 °C	Black	Solder	Forked	Push-Pull	Gold	1	Tin	4		0.09 in	Receptacle	5.1 A	All	Board Board or Cable		Phosphor Bronze	Square	Liquid Crystal Polymer (LCP)
Samtec Inc. SQT-110-03-S-Q	UL94 V-0	0.25 in	Through Hole	30 µin	0.079 in	125 °C	-55 °C	Black	Solder	Forked	Push-Pull	Gold	4	Tin	40	0.079 in	0.208 in	Receptacle	5.1 A	All	Board Board or Cable		Phosphor Bronze	Square	Liquid Crystal Polymer (LCP)
Samtec Inc. SQT-144-03-G-D	UL94 V-0	0.25 in	Through Hole	20 Ąin	0.079 in	125 °C	-55 °C	Black	Solder	Forked	Push-Pull	Gold	2	Gold	88	0.079 in	0.208 in	Receptacle	5.1 A	All	Board Board or Cable
Samtec Inc. SQT-133-01-S-D-RA	UL94 V-0	0.157 in	Right Angle Through Hole	30 µin	0.079 in	125 °C	-55 °C	Black	Solder	Forked	Push-Pull	Gold	2	Tin	66	0.079 in	0.09 in	Receptacle	5.1 A	All	Board Board or Cable
Samtec Inc. SQT-110-01-G-Q	UL94 V-0	0.25 in	Through Hole	20 Ąin	0.079 in	125 °C	-55 °C	Black	Solder	Forked	Push-Pull	Gold	4	Gold	40	0.079 in	0.09 in	Receptacle	5.1 A	All	Board Board or Cable
