Description
General part information
ROB-10847
Unipolar Stepper Motor Hybrid Frame Size 23 200.0 Step 2 A 3VDC
Technical Specifications
Parameters and characteristics for this part
| Specification | ROB-10847 |
|---|---|
| Coil Resistance | 1.5 Ohms |
| Coil Type | Unipolar |
| Current Rating | 2 A |
| Diameter - Shaft | 0.25 in |
| Features | Round Shaft |
| Length - Shaft and Bearing | 0.89 in |
| Mounting Hole Spacing | 1.856 in |
| NEMA Frame Size | 23 |
| Size / Dimension Length | 2.22 in |
| Size / Dimension Shape | Square |
| Size / Dimension Width | 2.22 in |
| Step Angle | 1.8 ° |
| Steps per Revolution | 200 steps |
| Termination Style | Wire Leads |
| Torque - Holding (mNm) | 900 mNm |
| Torque - Holding (oz-in) | 127.47 oz-in |
| Type | Hybrid |
| Voltage - Rated | 3 VDC |
