SFV 120
ActiveLumberg Inc
IP40 CHASSIS PLUG FRONTMOUNT
SFV 120
ActiveLumberg Inc
IP40 CHASSIS PLUG FRONTMOUNT
Description
General part information
SFV 120
12 Position Circular Connector Plug, Male Pins Solder
Technical Specifications
Parameters and characteristics for this part
| Specification | SFV 120 |
|---|---|
| Color | Silver |
| Connector Type | Male Pins, Plug |
| Contact Finish - Mating | Silver, Gold |
| Fastening Type | Threaded |
| Ingress Protection | IP40 |
| Material Flammability Rating | UL94 |
| Mounting Feature | Rear Side Nut, Bulkhead, Front Side Nut |
| Mounting Type | Panel Mount, Chassis Mount |
| Number of Positions | 12 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Primary Material | Metal |
| Shell Finish | Nickel |
| Shell Material | Zinc Die Cast |
| Shell Size - Insert | M16 |
| Termination | Solder |
