KTS1641QGDV-TR
ActiveKinetic Technologies
AUTOMOTIVE LOAD SWITCH WITH 20.3
KTS1641QGDV-TR
ActiveKinetic Technologies
AUTOMOTIVE LOAD SWITCH WITH 20.3
Description
General part information
KTS1641QGDV-TR
Power Switch/Driver 1:1 N-Channel 6A 12-TDFN (4x4)
Technical Specifications
Parameters and characteristics for this part
| Specification | KTS1641QGDV-TR |
|---|---|
| Current - Output (Max) | 6 A |
| Fault Protection | Reverse Current, UVLO, Over Temperature |
| Features | Status Flag |
| Input Ratio | 1 |
| Input Type | Non-Inverting |
| Interface | On/Off |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output Configuration | High Side |
| Output Ratio | 1 |
| Output Type | N-Channel |
| Package / Case | 12-DFN |
| Package Length | 4 mm |
| Package Name | 12-TDFN |
| Package Width | 4 mm |
| Rds On (Typ) | 41 mOhm |
| Switch Type | General Purpose |
| Voltage - Load (Max) | 40 V |
| Voltage - Load (Min) | 6 V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Voltage - Supply (Vdd/Vcc) | Not Required |
