Part	Mounting Type	Number of Outputs	Features	Power (Watts)	Efficiency	Applications	Standard Number	Voltage - Output 1	Voltage - Isolation	Current - Output 1	Size / Dimension Height	Size / Dimension Width	Size / Dimension Length	Type	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Input (AC) Minimum	Voltage - Input (AC) Maximum	Voltage - Output 2	Current - Output 2	Approval Agency	Minimum Load Required	Package / Case	Current - Output (Max) Options	Line Regulation	Weight	Load Regulation (Percent)	Current - Output (Max)	Current - Output 3	Voltage - Output 3
XP Power ECL05US15-T	Chassis Mount	1	Adjustable Output DC Input Capable Universal Input	5 W	80 %	ITE (Commercial)	62368-1	15 V	3 kV	330 mA	0.88 in	1.36 in	3.46 in	Open Frame	70 °C	-20 °C	85 VAC	264 V
XP Power ECL25US24-S	Chassis Mount	1	Adjustable Output DC Input Capable Universal Input	25 W	82 %	ITE (Commercial)	62368-1	24 V	3 kV	1.04 A	1.12 in	1.57 in	3.78 in	Enclosed	70 °C	-20 °C	85 VAC	264 V
XP Power ECL30UD02-T	Chassis Mount	2	Adjustable Output DC Input Capable Universal Input	30 W	83 %	ITE (Commercial)	62368-1	15 V	3 kV	1 A	0.88 in	1.36 in	3.46 in	Open Frame	70 °C	-20 °C	85 VAC	264 V	-15 V	1 A
XP Power ECL15US48-S	Chassis Mount	1	Adjustable Output DC Input Capable Universal Input	15 W	82 %	ITE (Commercial)	62368-1	48 V	4000 Vpk	320 mA	1.04 in	1.36 in	3.3 in	Enclosed	70 °C	-20 °C	85 VAC	264 V			CE	No
XP Power ECL30UD03-P	Through Hole	2	Universal Input	30 W	81 %	ITE (Commercial)	62368-1	5 V			1.05 in	1.36 in	2.96 in	Open Frame	70 °C	-20 °C	85 VAC	264 V			CSA cUL EN IEC UL		6-DIP Module	1.3A 3A	0.5 %	0.132 lb	1 %
XP Power ECL05US48-E	Through Hole	1	Universal Input	5 W	82 %	ITE (Commercial)	62368-1	48 V			0.91 in	1.07 in	2.06 in	Enclosed	70 °C	-20 °C	85 VAC	264 V			CSA cUL EN IEC UL		4-DIP Module		0.5 %	0.132 lb	1 %	100 mA
XP Power ECL30UT03-S	Chassis Mount	3	Adjustable Output DC Input Capable Universal Input	30 W	81 %	ITE (Commercial)	62368-1	5 V	3 kV	3 A	1.12 in	1.57 in	3.78 in	Enclosed	70 °C	-20 °C	85 VAC	264 V	15 V	500 mA									500 mA	-15 V
XP Power ECL25US48-T	Chassis Mount	1	Adjustable Output DC Input Capable Universal Input	25 W	82 %	ITE (Commercial)	62368-1	48 V	3 kV	520 mA	0.88 in	1.36 in	3.46 in	Open Frame	70 °C	-20 °C	85 VAC	264 V
XP Power ECL15US12-T	Chassis Mount	1	Adjustable Output DC Input Capable Universal Input	15 W	80 %	ITE (Commercial)	62368-1	12 V	3 kV	1.25 A	0.78 in	1.25 in	3.1 in	Open Frame	70 °C	-20 °C	85 VAC	264 V
XP Power ECL15US24-P	Through Hole	1	Universal Input	15 W	82 %	ITE (Commercial)	62368-1	24 V			0.96 in	1.21 in	2.44 in	Open Frame	70 °C	-20 °C	85 VAC	264 V			CSA EN IEC UL		4-DIP Module					630 mA
