XCSDMC791L01M8
ActiveSCHNEIDER ELECTRIC
SAFETY INTERLOCK SWITCH, PREVENTA XCS SERIES, DPST-NC, CABLE, IP67
XCSDMC791L01M8
ActiveSCHNEIDER ELECTRIC
SAFETY INTERLOCK SWITCH, PREVENTA XCS SERIES, DPST-NC, CABLE, IP67
Description
General part information
XCSDMC791L01M8
SAFETY INTERLOCK SWITCH, PREVENTA XCS SERIES, DPST-NC, CABLE, IP67
Technical Specifications
Parameters and characteristics for this part
| Specification | XCSDMC791L01M8 |
|---|---|
| Actuator Type | Non-Contact |
| Approval Agency | UL, CSA |
| Circuit | DPST-NC |
| Current Rating | 100 mA |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Must Operate (Length) | 5 mm |
| Must Release | 15 mm |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -25 °C |
| Termination Style | Cable with Connector (M8) |
| Type | Magnetic |
| Voltage Rating | 24 V |
