MK24-B-2-OE
ActiveStandex-Meder Electronics
SWITCH REED SPST-NC 300MA 30V
MK24-B-2-OE
ActiveStandex-Meder Electronics
SWITCH REED SPST-NC 300MA 30V
Description
General part information
MK24-B-2-OE
Molded Body Reed Switch SPST-NC 20 ~ 40AT Operate Range 3W 300mA (AC/DC) 30 V Surface Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | MK24-B-2-OE |
|---|---|
| Capacitance | 0.1 pF |
| Circuit | SPST-NC |
| Current - Carry | 0.5 A |
| Current - Carry Type | AC, DC |
| Current - Switching (AC/DC) | 0.3 A |
| Current - Switching Type | AC, DC |
| Height Above Board | 0.102 in |
| Length - Overall | 0.283 in |
| Mounting Type | Surface Mount |
| Operate Range (Max) | 40 AT |
| Operate Range (Min) | 20 AT |
| Operate Time | 0.25 ms |
| Operating Temperature (Max) | 115 °C |
| Operating Temperature (Min) | -40 °C |
| Power - Rated | 3 W |
| Release Range (Max) | 35 AT |
| Release Range (Min) | 10 AT |
| Release Time | 0.15 ms |
| Size - Body Height | 0.102 in |
| Size - Body Length | 0.197 in |
| Size - Body Width | 0.087 in |
| Termination Style | Gull Wing |
| Type | Molded Body Reed |
| Voltage - Switching AC | 30 V |
| Voltage - Switching DC | 30 V |
