HSS13-B20-NP
ActiveSame Sky (Formerly CUI Devices)
HEATSINK: EXTRUDED; U; TO220; BLACK; L: 31MM; W: 25.25MM; H: 12.9MM
HSS13-B20-NP
ActiveSame Sky (Formerly CUI Devices)
HEATSINK: EXTRUDED; U; TO220; BLACK; L: 31MM; W: 25.25MM; H: 12.9MM
Description
General part information
HSS13-B20-NP
Heat Sink TO-220 Aluminum Alloy 4.8W @ 75°C Board Level, Vertical
Technical Specifications
Parameters and characteristics for this part
| Specification | HSS13-B20-NP |
|---|---|
| Fin Height | 0.508 in |
| Length | 1.22 in |
| Material | Aluminum Alloy |
| Material Finish | Black Anodized |
| Package Cooled | TO-220 |
| Power Dissipation | 4.8 W |
| Shape | Rectangular |
| Thermal Resistance | 15.5 °C/W, 7.7 °C/W |
| Type | Vertical, Board Level |
| Width | 0.994 in |
