B15-12CS
ActiveCentury Spring Corp
COMP O= .406,L= .63,W= .061
B15-12CS
ActiveCentury Spring Corp
COMP O= .406,L= .63,W= .061
Description
General part information
B15-12CS
COMP O= .406,L= .63,W= .061
Technical Specifications
Parameters and characteristics for this part
| Specification | B15-12CS |
|---|---|
| Diameter - Inside | 0.284 in |
| Diameter - Outside | 0.406 in |
| End Style | Closed |
| Finish | None |
| Free Length | 0.63 in |
| Material | Spring Steel |
| Rate (lbs/in) | 162 lbs/in |
| Type | Compression |
| Wire Diameter | 0.061 in |
